Metevo MX-1417
Entry-level automated panel bender, specifically designed for high-performance serial production of sheet metal parts with a maximum bending length of 1400 mm.
• Flexible automation The use of universal tooling allows for a wide range of standard bends, while manual adjustment of the blank holder (BMS) takes only 8–10 minutes, which is optimal for medium and large production batches.
• Stable technology Applied technical solutions, including a fully electric manipulator and pneumatic drives, guarantee reliability and high performance. The equipment features long-term durability with a tool life of approximately 1 million bends, ensuring stable quality with minimal maintenance.
• Adaptive system Intuitive 2D software and factory calibration for the customer's working thickness range allow for rapid production startup and minimize operator errors. The system is optimized for standard materials, ensuring high angular precision without complex setup requirements.
• 4.0 Connectivity The proprietary MX HMI software environment and optional 3D CAM module provide convenient machine control and direct import of STEP files to speed up the programming process. Support is provided through local Salvagnini service centers, ensuring fast access to expertise and spare parts.
• Stable technology Applied technical solutions, including a fully electric manipulator and pneumatic drives, guarantee reliability and high performance. The equipment features long-term durability with a tool life of approximately 1 million bends, ensuring stable quality with minimal maintenance.
• Adaptive system Intuitive 2D software and factory calibration for the customer's working thickness range allow for rapid production startup and minimize operator errors. The system is optimized for standard materials, ensuring high angular precision without complex setup requirements.
• 4.0 Connectivity The proprietary MX HMI software environment and optional 3D CAM module provide convenient machine control and direct import of STEP files to speed up the programming process. Support is provided through local Salvagnini service centers, ensuring fast access to expertise and spare parts.
| Parameter | Value |
| Max bending length | 1400 mm |
| Max diagonal that can be rotated | 1980 mm |
| Max bending height | 170 mm |
| Min thickness | 0.4 mm |
| Max thickness mild steel (UTS 410 N/mm²) | 2.0 |
| Max thickness stainless steel (UTS 515 N/mm²) | 1.5 |
| Max thickness aluminium (UTS 265 N/mm²) | 3.0 |
| Max inward bend on long side | 40 mm |
| Max inward bend on short side | 30 mm |
| Min blankholder step | 10 mm |
| Average power | 3 kW |
| Footprint | 10 m² |
| Weight | 13 ton |
Metevo is a brand owned by Salvagnini (Italy). It operates globally through the Salvagnini distribution network. Production of panel bender is based in China, while distribution is exclusively managed by Salvagnini. Each Salvagnini distribution company oversees commercial activities and provides local after-sales support through its own service organization. This ensures faster response times, local language assistance, and direct customer interaction across all supported regions.
